mcm_functionality (Entity)

Normalize: T

Description:

@1 mcm_func_seq+
spy_channel1_ok+
spy_channel2_ok+
amu_adc_ok+
adc_linearity_ok+
xi_link1_ok+
xi_link2_ok+
correlator_ok+
discriminator_ok+
trigger_ok+
@2 mcm_id / FKFROM &quotmcm.mcm_id(mcmid_func_fk)"/

Definitions Used:

mcm_id (Data Element)
mcm_func_seq (Data Element)
spy_channel1_ok (Data Element)
spy_channel2_ok (Data Element)
amu_adc_ok (Data Element)
adc_linearity_ok (Data Element)
xi_link1_ok (Data Element)
xi_link2_ok (Data Element)
correlator_ok (Data Element)
trigger_ok (Data Element)
discriminator_ok (Data Element)

Return to diagram

mcm (Entity)

Description:

@mcm_id
mcm_cable_id
visual_ok
wirebond_ok
wirebond_comment
visual_comment

Normalize: T

Definitions Used:

mcm_id (Data Element)
mcm_cable_id (Data Element)
visual_ok (Data Element)
wirebond_ok (Data Element)
wirebond_comment (Data Element)
visual_comment (Data Element)

Return to diagram

adc_linearity_check (Entity)

Normalize: T

Description:

@1 adclin_check_seq+
adclin_bad_channel_id+
@2 mcm_id / FKFROM &quotmcm.mcm_id(mcmid_adc_fk)"/

Definitions Used:

mcm_id (Data Element)
adclin_check_seq (Data Element)
adclin_bad_channel_id (Data Element)

Return to diagram

amu_adc_check (Entity)

Normalize: T

Description:

@1 amu_adc_check_seq+
amuadc_bad_channel_id+
@2 mcm_id / FKFROM &quotmcm.mcm_id(mcmid_amu_fk)"/

Definitions Used:

mcm_id (Data Element)
amu_adc_check_seq (Data Element)
amuadc_bad_channel_id (Data Element)

Return to diagram

mcmid_amu_fk (Relation)

From Entity: mcm

To Entity: amu_adc_check

Identifying: T

From Entity: mcm

To Entity: amu_adc_check

Parent Update: Cascade

Parent Delete: Cascade

Child Insert: Restrict

Child Update: Restrict

Return to diagram

mcmid_func_fk (Relation)

From Entity: mcm

To Entity: mcm_functionality

Identifying: T

From Entity: mcm

To Entity: mcm_functionality

Parent Update: Cascade

Parent Delete: Cascade

Child Insert: Restrict

Child Update: Restrict

Return to diagram

mcmid_adc_fk (Relation)

From Entity: mcm

To Entity: adc_linearity_check

Identifying: T

From Entity: mcm

To Entity: adc_linearity_check

Parent Update: Cascade

Parent Delete: Cascade

Child Insert: Restrict

Child Update: Restrict

Return to diagram
